Raw Cashew Grading Machine | Cashew Nut Grader


Model | TZ-YG 400 |
Capacity | 400 kg/h |
Power | 1.1 kw |
Voltage | 380v 50hz |
Dimension | 3800*900*1600mm |
Weight | 350 kg |
You can now ask our project managers for technical details
Cashew nut grading machine is divided into raw cashew nut grading machine and cashew kernel grading machine. These two machines can quickly help customers sift out different sizes of raw cashew nuts and cashew kernels.


Table of Contents
Introduction of row cashew nut grading machine
This raw cashew grading machine is a previous processing step of the whole production line. It could lessen the workloads of the following processing. And the easy operation enables any plant to use this machine. Of course, you can choose to use this grader separately or in a production line.
The character of Raw Cashew Grading Machine
The cashew grader is used for sorting the nuts into several different grades in order to improve the next opening shell rate. It usually includes 3 to 5 grades: <18 mm, 18-20 mm, 20-22mm, 22-24 mm, 24-26 mm, and>26mm. And this could be made according to the customer’s requirements.
This machine is composed of transmission, hierarchy, chassis, and other components. It doesn’t have a complex structure and it is automatic.


Operation Methods of Raw Cashew Grading Machine
- Check the circuit before starting.
- Connect the power supply according to the arrow direction, and remember operation is irreversible.
- Continuously pour raw fruits into the hopper, adjust the size of the feeding door, and enter the uniform grading barrel of cashew nuts.
- The classification bucket has three different sizes of holes, corresponding to the following receiving hopper.
- The cashew grading barrel rotates under the rotation, and also leaves a small number of nuts to reclassify.
- The large nuts rotate from the drum to the next level over and over, to achieve the effect of the classification.
- Though the drum rotating, nuts get through a single plugging hole to the deburring roller rotate synchronously, and are sent into the air.
Technical Parameter
Model | TZ-YG 400 |
Capacity | 400 kg/h |
Power | 1.1 kw |
Voltage | 380v 50hz |
Dimension | 3800*900*1600mm |
Weight | 350 kg |
Actually, we grade cashew before further processing not only for convenience but also for their market value, or simply, price. Mostly, sellers will package cashew nuts according to their size and sell them at different prices. Plants choose to grade cashew at the first step or last. Anyway, the grading is to realize the most value of nuts. Therefore, a raw cashew grading machine is necessary.
Introduction of cashew kernel grading machine
Unlike the raw cashew nut grading machine, the cashew kernel grader machine is the last process of the cashew nut processing line. The cashew nuts processed by this cashew kernel grader machine will be sieved according to different sizes. The merchant can pack and sell the cashew nuts according to different indexes.

How is cashew kernel graded?
There are three layers of drums on the cashew kernel grader machine. Each layer of drums can sieve one size of cashew kernels. Therefore, the cashew nut size sorting machine can sieve cashew kernels according to 3 different grades. Customers can also adjust the gap between the rollers to achieve the size they want according to their actual needs.

Technical parameters of cashew kernel grading machine
Model | TZ-K500 |
Capacity(kg/h) | 500 |
Power(kw) | 0.75 |
Voltage(v) | 380 |
Frequency(hz) | 50 |
Size(m) | 2×0.8×1.4 |
Weight(kg) | 300 |
Summary
If you need raw cashew grader or cashew kernel grading machine, please feel free to contact us. We will contact you as soon as possible and will give you a detailed quotation.
